Galvanised Steel Triangle Panels Roll Forming Machine For Furring

Main Technical dates:

1) Suitable material: galvanized steel coil

2) Thickness of coil sheet: 0.3-0.5mm

3) Coil width: as customer's profile drawing requirement

4) Effective width: as customer's profile drawing requirement

5) Material of main frame : welded by square pipe

6) Diameter of Soild shaft: 40mm, high grade 45# steel

7) Roller: Cr12

8) Thickness of middle plate: Memorial archway

9) Forming station: 12-14 rows

10) Drive type: Gear

11) Power of main motor: 4.0 kw with reducer

12) Servo motor: 2.2KW Touch-win

13) Forming speed: About 25-30m/min

14) Hydraulic pump station: 4.0 kw, 46# hydraulic oil

15) PLC: Touch-win,Wuxi

16) Material of cutting blades: Cr 12 Mov, quenching 58-62℃

17) Frequency converter: It has the advantage of slowing down before cutting, to ensure the length accuracy ±1mm, far better than industrial standard ±3mm.

18) Switch: CHNT

19) Frequency changer: Touch-win,Wuxi

20) Cutting way: No-stop cutting way

21) Galvanised Steel Triangle Panels Roll Forming Machine For Furring making profile( Also can customize)
