Main parameter of Double Furring Metal Trusses Ceiling Panels Purlin Forming Rolling Machine:
1), Length of the main part: 4000*1200*1300mm
2), Weight of main part: About 3 t
3), Voltage: 380V/50HZ3Phase (as customer's request)
4), Roller fixer: Guide column
5), Frame: Middle plate welded memorial arch frame type
6), Frame thickness: 25mm
7), Drive mode: Gear or chain
8), Material of rollers: 45# steel with tempering
9), Material of shafts: 45# steel with tempering
10), Diameter of shafts: φ40mm
11), Number of rollers: 10-14 rollers
12), Main power: 3kw (Cycloidal planetary gear speed reducer)
13), One Machine Can make many different model truss and ceilling profiles
14), Warranty: One year
15), Double Furring Metal Trusses Ceiling Panels Purlin Forming Rolling Machine Drawing:
16), Double Furring Metal Trusses Ceiling Panels Purlin Forming Rolling Machine Photo Show:
