Easy operate, low maintenance cost
Stable and durable
Save materials, no waste
With black treatment or hard-chrome coating for options
With feeding material guide, body frame made from 300 H steel or 350 H steel welcidng
Made by high quality mold steel Cr12 with heat treatment
Cutter frame made from high quality 20mm steel plate by welding
Hydraulic motor: 4KW
Manual decoiler: One set
Un-powered, manually control steel coil inner bore shrinkage and stop
Max feeding width: 500mm Coil range:470-550mm
Suitable for materials thickness: 0.3-0.8mm
Shaft materials: 45# Steel
Shaft diameter: 70mm
Forming speed: 8-15m/min
De-coiler—→Level device —→Main roll forming machine—→Hydraulic cutting—→ Run out table
