Floor Deck Panel Roll Forming Machine
  • Floor Deck Panel Roll Forming Machine

Floor Deck Panel Roll Forming Machine

Steel Equipment,Steel Products, Plastic Film Rolls Exporter
Description




Floor Deck Oanel Roll Forming Machine


Main Technical Paramaters Of Machine
*Suitable Material: Color Steel Plate, galvanized plate, or aluminium plate
*Material Thickness: 0.8-1.2mm *Material Width: 1000mm(according to the profile)
*Diameter of Shaft: 90mm * Roller Station: 25 Steps(according to the profile)
*Sidewall Thickness: 18mm *Main Frame: 350H Steel

*Motor Power: 15KW+5.5KW *Forming Speed: 8-12m/min
*Cutting Device: Hydraulic Cutting *Material Of Blade: Cr12
*Drive Way: By Chain
Component Of Floor Deck Roll Forming Machine

*Manual Deciler .................... 1 Unit
*Main Roll Forming Machine .................... 1Unit
*Hydraulic Pump .................... 1 Unit
*PLC Control Cabinet .................... 1Unit
*Discharge Table .................... 1 Unit
*Spare Part .................... 1Unit
