Australlian Saudi Style Rolling Shutter Door Machine can produce steel shutter door slats in galvanized sheet, pre-painted sheet or stainless steel sheet. Steel shutter door slats are used as the doors for work plants and shops because of durable use, space saving, low cost and low noise.
Steel strip supporting frame
Feeding platform
Automatic shearing system
Hydraulic system Steel strip unfolding system
Computer control system (imported computer)
High-precision automatic counter
Receiving table
1) Suitable material: colored steel sheet, aluminium steel sheet, and galvanized steel sheet
(2) Thickness of the plate:0.3-0.8 mm
(3) Input width of the plate:Based on detailed design
(4) Width of the plate after forming: Based on detailed sizes
(5) Productivity:0-20m/min
(6) Roller steps:14 rows
(7) Roller material:45#steel Rolling chromiumthickness:0.05mm
(8) Diameter of active shaft: 56-70mm ( Solid shaft)
(9) Wall thickness of the main forming machine:14mm steel plate
(10) Main forming machine body:350mmH steel
(11) Transmission chain is 1inches
Reducer is 4kwwhich works stably and no noise
