Raw material : Color Steel Sheet Coil/Glavanized Steel Coil
Feeding Width : 1220mm/1220mm
Effective width : 1035/1110mm
Thickness : 0.3-0.7mm
Machine Weight : About 6.0Tons
Dimension of machine : About 8.6m*1.65m*1.55m
Shaft station : 14/16 Stations
Rolling speed : 0-19m/min
Transmission: By chain
Size of Chain : 1.0 inch
Material of Roller : 45# Steel plated hard
Power of main motor : 5.5KW
Cutter materials : GCr12 steel with quenched treated 60-62°C
Control system : PLC Control Box
Cutting way : Automatic Manual two control way
Voltage : 380V/50HZ,3PH ( also can do based on your requirement)
Machine color : Do based on you need
