1, Galvanized Steel Rolling Shutter Door Slats Roller Machine For Brazil Main Components:

    3T Decoiler, Roll forming machine, PLC cabinet, Hydraulic station , Output table(2)

2, Galvanized Steel Rolling Shutter Door Slats Roller Machine For Brazil Flow Chart:

    Passive decoiler----Feeding----Forming----Hydraulic Cutting----Runout table

3, Galvanized Steel Rolling Shutter Door Slats Roller Machine For Brazil Main Technical dates:

   1) Main power: 4KW

   2) Roller stations: 10-12stations

   3) Drive way: By chain,1.0 inch single chain drive

   4) Diameter of shaft: 50mm

   5) Cutting system: hydraulic cutting

   6) Length tolerance: ±1.5mm

   7) Working speed: 0-20 m/min

   8) Thickness: 0.3-0.8 mm

   10) Material of shaft: 45# steel

   11) Hydraulic pressure: 12 Mpa

   12) cutting saw power: 3kw

   14) Control system: PLC Control

   15) Size of machine: approx 4m*1.0m*1.0m

4，Galvanized Steel Rolling Shutter Door Slats Roller Machine For Brazil in our factory:
